Secondary Roads
6,000-15,000 lm options support road layouts with recommended mounting heights from 5 to 10 m.
RSE Series All-in-One Solar Street Light
The RSE Series is an all-in-one solar street light with 6,000-15,000 lm output for roads, parking areas, industrial parks and off-grid lighting projects.
Choose from RSE-60, RSE-100 and RSE-120 according to road width, pole height, lighting requirements and local solar conditions.
- 6,000-15,000 lm Output
- 60-120 W Solar Panel
- 240-640 Wh LiFePO4 Battery
- 5-10 m Mounting Height
Technical Specifications
Compare the RSE-60, RSE-100 and RSE-120 all-in-one solar street light configurations for urban roads, residential streets, parking areas and infrastructure projects.
| Model | RSE-60 | RSE-100 | RSE-120 |
| LED quantity | 140 pcs | 240 pcs | |
| Luminous flux | 6000lm | 10000lm | 15000lm |
| Beam angle | 150*70° | ||
| LED lifespan | 50000hrs | ||
| IP rating | IP65 | ||
| Operating temperature | -20°C~60°C（Charge above 0°C） | ||
| Color temperature | 3000-7500K | ||
| CRI | Ra≥70 | ||
| Solar panel power | 60W | 90W | 120W |
| Solar panel voltage | 18V | ||
| Solar cell efficiency | 22-24% | ||
| Solar panel material | Monocrystalline silicon | ||
| Battery capacity | 240Wh / 75Ah | 384Wh / 120Ah | 640Wh / 200Ah |
| Battery type | LiFePO4 | ||
| Lighting time (full charge) | 5-7 rainy days | ||
| Pole top diameter | 76mm | ||
| Recommended mounting height | 5-7m | 7-9m | 8-10m |
| Recommended pole spacing | 20-40m | ||
*Need more technical information? Contact our engineering team to receive the complete datasheet, IES files, DIALux lighting simulation and customized project recommendations.
RSE Series Advantages
The RSE Series combines efficient LED lighting, LiFePO4 energy storage and road-oriented optics for reliable off-grid street lighting.
High-Efficiency LED LightingOverall lighting efficiency above 160 lm/W supports bright and uniform road illumination.
Grade-A LiFePO4 BatteryCurrent equalization and dual protection support stable battery performance.
Multi-Peak MPPT ControlMulti-Peak MPPT and IPC 5.0 help manage solar charging and lighting output.
Road-Ready OpticsA 150° × 70° light distribution supports road-oriented lighting layouts.
Modular All-in-One DesignIntegrated components simplify transportation, installation and maintenance.
RSE Series Applications
RSE all-in-one solar street lights are designed for roads, parking areas, industrial sites and off-grid outdoor lighting projects.
Parking Areas
The integrated design reduces separate components for parking area installation and maintenance.
Industrial Parks
LiFePO4 storage and IPC 5.0 control support scheduled lighting for industrial and logistics sites.
Residential Roads
The 150° × 70° distribution supports road-oriented lighting for residential communities.
Rural and Off-Grid Roads
A practical solar lighting option for sites where grid connection or cable trenching is difficult.
Campuses and Parks
IP65 protection and 76 mm pole-top compatibility support public outdoor lighting installations.
Engineering Support for Solar Street Light Projects
1、Project Requirement Review
● Road Width Assessment
● Pole Height Confirmation
● Lighting Hour Planning
2、Model & Configuration Advice
● Wattage Selection
● Battery Capacity Matching
● Solar Panel Sizing
3、Lighting Layout Support
● Pole Spacing Reference
● Installation Layout Suggestion
● Application Matching
4、Installation Guidance
● Mounting Advice
● Bracket & Foundation Reference
● Start-Up Check Support
5、Project Document Support
● Datasheets
● Specification Sheets
● Configuration Records
6、After-Sales Technical Assistance
● Troubleshooting Support
● Maintenance Guidance
● Spare Parts Advice
7、Project Follow-Up
● Sample Evaluation
● Delivery Coordination
● Ongoing Project Communication
Need a Customized Solar Street Light Solution
Send us your project details, including road width, pole height, installation location, required lighting hours, quantity and local solar conditions. Our engineering team will recommend the most suitable RSE Series configuration and provide a project-specific solution.
Request a Professional Solution
Please submit your project details on the right. Our team will provide a professional solution and quote via email within 24 hours.
Related Products
FAQ
Q: Can RoadSmart support bulk orders and project procurement?
Yes. Please send the required models, quantity, destination, delivery schedule and project specifications. RoadSmart will confirm the configuration, commercial terms and delivery plan.
Q: What documents are available for project approval?
Customers can request product datasheets, technical specifications, configuration records, IES files, DIALux simulations and applicable certification documents for project review.
Q: Can RoadSmart provide IES files and DIALux simulations?
Yes. IES files, DIALux lighting simulations, model selection advice and project-specific lighting recommendations can be requested from the RoadSmart engineering team.
Q: Is the RSE Series easy to install?
The integrated design combines the solar panel, LiFePO4 battery, controller and LED lighting module in one fixture. This helps reduce separate components and onsite wiring during installation.
Q: Can the RSE Series replace conventional grid-powered street lights?
The RSE Series can be considered for projects where grid connection, trenching or cable installation is difficult. Final suitability should be confirmed through a lighting layout and energy assessment.
Q: How does the RSE Series perform during cloudy or rainy weather?
When fully charged, this product can provide continuous illumination for 5 to 7 days, even in overcast or rainy weather. Actual performance may vary based on sunlight conditions, duration of illumination, operating mode, local environment, and the project's specific location.
Q: Can the RSE Series be used in areas without grid electricity?
Yes. The RSE Series is an all-in-one solar street light designed for off-grid outdoor lighting projects, including rural roads, remote areas, parks, campuses and industrial sites.
Q: What project information is needed for a solar street light quotation?
Please provide the project location, road width, pole height, pole spacing, required lighting hours, quantity, installation conditions and expected delivery schedule. Our engineering team can then recommend a suitable RSE configuration.
Q: Which RSE model is suitable for my lighting project?
The RSE Series includes RSE-60, RSE-100 and RSE-120 models with 6,000-15,000 lm output. The suitable model depends on road width, pole height, pole spacing, lighting requirements and local solar conditions.
